Tremoline FT36 Tremolo Systems
Original Fine Tuning Double Locking Tremolo System
DESCRIPTION
The Tremoline FT36 is unique and presents a new Original Fine Tuning Double Locking Tremolo system patented in the USA, Germany and other countries.
The concept for the appearance is the achievement of BETTER PERFORMANCE through more CONVENIENCE and SOUND QUALITY.
The tremolo system is not only a fully functional RETROFIT of the most widely spread Double Locking Tremolo System, but also it retrofits some of the 2-point (74.2mm) non-locking tremolos.
It can be equipped with one of four types of Locking Nuts - right handed - R2 (width-41.4mm) or R3 (width-42.8mm) and left handed - L2 or L3.
There are two fixing options for Locking nuts - from above (by two wood screws) and from underneath (by two metric thread screws).
The Tremoline FT36 is the only tremolo system that allows the guitar pick usage for adjustment. In this way the fine tuning process is simple, quick and intuitive.
It is very easy to do this adjustment also with key wrench, Adjustment screw head or your finger nail.
All fine tuning springs are hidden mounted into the saddle assembly bodies.
The unit string radius is R16” (406.4mm), achieved by three types of saddle assemblies with different height for 1-6, 2-5, 3-4 string pairs.
The tremolo arm spring is hidden mounted into the Sustain Block in order to avoid any backlash of the tremolo arm.
All metal parts are produced only from solid bars, sheets and wires of specially selected STAINLESS STEEL alloys.
All parts are NON-MAGNETIC, which leads to the lack of magnetic interference (unwanted noise).
The only plastic part is made of specially selected engineering plastics, which withstand heavy loads, is acid-resistant, dimensionally stable and long lasting.
All parts comply with RoHS 2 (European Directive 2011/65/EU for the Restriction of use of certain Hazardous Substances).
All parts are NON-ALLERGENIC and comply with ISO 10993-10 (European standard for biocompatibility) and are also FDA (U.S. Food and Drug Administration) compliant.
The Tremoline FT36 (with its low and flat top profile) is the right solution for guitar players who often use both Guitar Techniques - Vibrato and Palm Muting.
TECHNICAL DATA
| Tremolo Unit type | R3 |
| E-E Center width |
52.0mm / 2.06" |
| String spacing | 10.4mm / 0.41" |
| Pivot Stud spacing | 74.2mm / 2.92" |
| Tremolo Unit radius | 405.4mm / 16.0" |
| Sustain Block thickness | 12.0mm / 0.4724" |
| Sustain Block Height | 33.0mm / 1.30" |
| Nut Unit type | R3 - Right handed |
| Nut Base width |
42.8mm / 1.6875" |
| E-E center width | 36.0mm / 1.4155" |
| String spacing | 6.6mm / 0.2591" |
| Locking Nut radius | 304.8mm / 12.0" |
| Nut Base fixing | from above - underneath |
| Retainer Bar kit | included |
SPECIFICATION
Tremoline FT36 tremolo system set includes following parts:
| Tremolo Unit set: | 1 |
| - Baseplate |
1 |
| - Sustain Block | 1 |
| - Retainer Bar | 1 |
| - Saddle Assembly * | 6 |
| - String Lock Insert | 6 |
| - Fine Tuning Screw | 6 |
| - Saddle Mounting Screw | 6 |
| - String Lock Screw | 6 |
| - Trem Mounting Screw | 2 |
| - 10mm Retainer Screw | 2 |
| - Shim Ring | 12 |
| - Tremolo Arm Spring | 1 |
| - Tremolo Arm Sleeve-S | 1 |
| - Tremolo Arm Sleeve-P | 1 |
| - Tremolo Arm Screw | 1 |
| Spring Claw | 1 |
| Adjustment Screw | 1 |
| Pivot Stud | 2 |
| Pvot Insert | 2 |
| Tremolo Arm | 1 |
| Tremolo Spring | 4 |
| Spring Claw Screw | 2 |
| Clamp Cable Lug | 1 |
| Cable Lug Screw | 1 |
| Key wrench 1.5mm | 1 |
| Key wrench 2.5mm | 1 |
| Key wrench 3.0mm | 1 |
| Retainer Plate | 1 |
| 12mm Retainer Screw | 2 |
| Locking Nut Base | 1 |
| Locking Nut Clamp | 3 |
| Clamp Screw | 3 |
| Calmp Washer (opt.R2/L2) | 0 |
| Nut Mounting Screw | 2 |
| Nut Mounting Bolt | 2 |
| Nut Mounting Washer | 2 |
| Nut Bar | 1 |
| Nut Bar Screw | 2 |
| User Manual | 1 |
*String Saddle Assemblies (1-6,2-5,3-4) include a Front Saddle, Rear Saddle, Saddle Assembly Shaft and Hidden Fine Tuning Spring.
** Only R2 and L2 Locking Nuts include 3 pcs Clamp Washers.
OPTIONS and PURCHASING
Tremoline FT36-R3-SP
| Material | Stainless Steel |
| Orientation: | Right handed |
| Locking Nut type | R3 (42.8mm) |
| Coating Finish color | No Finish coating |
| Surface type | Polished |
Tremoline FT36-L3-SP
| Material | Stainless Steel |
| Orientation: | Left handed |
| Locking Nut type | L3 (42.8mm) |
| Coating Finish color | No Finish coating |
| Surface type | Polished |
Tremoline FT36-R2-SP
| Material | Stainless Steel |
| Orientation: | Right handed |
| Locking Nut type | R2 (41.4mm) |
| Coating Finish color | No Finish coating |
| Surface type | Polished |
Tremoline FT36-L2-SP
| Material | Stainless Steel |
| Orientation: | Left handed |
| Locking Nut type | L2 (41.4mm) |
| Coating Finish color | No Finish coating |
| Surface type | Polished |
PURCHASE through REVERB
FILES - technical information
| FT36_1E_EN [pdf] | Brief preview |
| FT36_2E_EN [pdf] | Part list |
| FT36_3C_OFR-LH_EN [pdf] | Routing scheme OFR LH |
| FT36_3C_OFR-RH_EN [pdf] | Routing scheme OFR RH |
| FT36_3C_STR-LH_EN [pdf] | Routing scheme OFR LH |
| FT36_3C_STR-RH_EN [pdf] | Routing scheme OFR RH |
| FT36-MB-EN-20220301 [pdf] | User manual |
| - | - |
